    Environmental Friendly Polypropylene Plastic Pipe , Custom Plastic Water Pipe

    Ask Lasest Price
    Brand Name : DSTHERM
    Model Number : 20-160mm
    Certification : ISO9001
    Price : Negotiation
    Supply Ability : 20days /20 feet container , 35days/40 HQ
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    Environmental Friendly Polypropylene Plastic Pipe , Custom Plastic Water Pipe


    New Design Best Price 100% Full Test PPR Pipe factory with 25 years experience 20-160mm

    Outer Diameter(mm)Thickness(mm)
    S5s4S3.2S2.5(customized)
    20+0.32.0+0.32.3+0.42.8+0.43.4+0.5
    25+0.32.3+0.42.8+0.43.5+0.54.2+0.6
    32+0.32.9+0.43.6+0.54.4+0.65.4+0.7
    40+0.33.7+0.54.5+0.65.5+0.76.7+0.8
    50+0.34.6+0.65.6+0.76.9+0.88.3+1.0
    63+0.35.8+0.77.1+0.98.6+1.010.5+1.2
    75+0.36.8+0.88.4+1.010.3+1.212.5+1.4
    90+0.38.2+1.010.1+1.212.3+1.415.0+1.6
    110+0.310.0+1.012.3+1.415.1+1.718.3+2.0
    125+0.311.4+1.314.0+1.517.1+1.920.8+2.2
    140+0.312.7+1.415.7+1.719.2+2.123.3+2.5
    160+0.314.6+1.617.9+1.921.9+2.326.6+2.8

    1.High Temperature Resistance:

    PPR pipe's maximum sustained working temperature is up to 70°C , the maximum transient temperature is up to 90°C .


    2.Heat Preservation:

    PPR pipe's low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe.


    3.Non-toxic:

    no heavy metal additives, our PN25 pp materials plastic food grade ppr pipe with red blue color line would not be covered with dirt or contaminated by bacterium.


    4.Corrosion Resistance:

    resist chemical matters and electron chemical corrosion.


    5.Low Installation Costs:

    light weight and ease of installation can reduce installation costs.


    6.Longevity: more than 50 years under proper use.


    7.Recycled and Environment-friendly.



    Advantages of using PPR pipe:

    ♦ Health and environmental protection. Polypropylene is environmentally friendly materials, can be used to make drinking water delivery.

    ♦ Joint with hot melt connection, become a whole, 100 percent no leakage, other materials with silk mouth connection, its permeability less, also avoid the glue bonding of toxic.
    ♦ High temperature resistance, good pressure resistance, small conveying resistance.
    ♦ The price is cheap and affordable.
    ♦ Long service life, according to the national standard GB/T18742 production and use can be used for 50 years.


    Parameters of the PPR Pipe SDR11/S5/PN10
    Nominal Outer DiameterDiameterWall ThicknessInner Diameter
    20202.016.0
    25252.320.4
    32322.926.2
    40403.732.6
    50504.640.8
    63635.851.4
    75756.861.4
    90908.273.6
    1101101090.0
    16016014.6130.8
